China Automatic And Intelligent Granule Packing Machine Pouch Filling Packing Machine

sku:

The granule filling packing machine can automatically complete the functions of automatic measurement, automatic filling, automatic bag making (printable), sealing and cutting of fixed packaging of products. The automatic intelligent packing machine has functions such as self-alarm, self-shutdown, self-diagnosis, etc. It is safe and simple to use, fast to maintain, and automatically displays the number of packages, which is convenient for counting the workload of the machine.

tag:

Description

China Automatic And Intelligent Granule Packing Machine Pouch Filling Packing Machine



The granule filling packing machine can automatically complete the functions of automatic measurement, automatic filling, automatic bag making (printable), sealing and cutting of fixed packaging of products. The automatic packing machine has functions such as self-alarm, self-shutdown, self-diagnosis, etc. It is safe and simple to use, fast to maintain, and automatically displays the number of packages, which is convenient for counting the workload of the machine.Our product specifications and sizes are rich, various styles, welcome to contact us for quotation information.


Automatic intelligent granule packing machine


Pouch Filling Packing Machine

Intelligent Granule Packing Machine

China Automatic And Intelligent Packing Machine






Measurement range: 20 ~ 1000G, 500 ~ 5000G


Packing speed: 20~ 50 packs/min


Bag size: (50~ 340)> (80 ~ 260) MM (length x width weighing accuracy: soil 0.2%


Compressed air requirement: 0.6 MPA0.65M3 / MIN Maximum allowable outer diameter of packaging material: Medium 400 MM


Inner diameter of roll paper core: medium 75 MM


Machine weight: 1000 KG


Power supply: 5.5KW 380V soil 109% 6 50HZ



Our goal is to provide you with the perfect automatic packing machine solution, support customization, and explain to our company the situation of packaging materials, packaging equipment (bag size, material), etc., expected output, etc., in order to provide you with suitable models. . If there are any other technical requirements, we will try our best to solve them.


Please provide the following information when sending an inquiry, so that we can quickly provide you with accurate feedback and suitable solutions.

Product details (product name, min/max dimensions and weight).

Packaging details (packaging material, size, shape).

capacity and detection accuracy requirements.

Other special requirements.





Optional device:

1. ESS series host

2, 2, ten or more computer combination scales

3. Z-type material conveyor

4. Vibrating feeder

5. Electronic scale platform

6. Finished product delivery

7. Support platform

8. Disc sorting machine

9. Metal detector



1. Chinese and English touch screen display, intuitive and simple operation.


2. PLC computer control system, the operation is more stable, and any parameters can be adjusted without stopping.


3. Ten groups of parameters can be stored, and the replacement of varieties is more accurate.


4. Using dual servo motor control, the film pulling is more accurate and faster.


5. Independent temperature control system, the temperature can reach ±1℃.


6. The temperature of horizontal and vertical sealing is independently controlled, and it can be well applied to packaging materials such as film and PE film.


7. Packaging styles are diversified (three-side seal, four-side seal, triangle bag, handbag), back seal, gusset, even bag, punching, etc.


8. The production of bag making, sealing, packaging, and date printing is completed at one time.



Automatic intelligent packing machine can automatically package products without human. Its main uses: pesticides, fertilizers, veterinary drugs, feed, premixes, additives, washing powder, salt, monosodium glutamate, chicken essence, sugar, seeds, Granular and powdery materials such as rice can be packaged quantitatively. It is suitable for automatic weighing and packaging of all kinds of loose particles and fine particles, and can automatically complete the whole set of packaging processes such as weighing, bag making, packaging, sealing, printing, and counting. Automatic intelligent packing machine can be connected with batching and automatic packing equipment to form batching packaging production line.






About our company


1. Founded in 2010.


2. Shanghai high-tech enterprise.


3. We have more than 10 years of experience in the field of packaging machinery and have our own factory, which can provide you with the most suitable items for your needs.


4. There are 6-8 international machinery exhibitions every year.


5. Supply OEM/ODM manufacturing.


6. Multiple engineers to ensure quality/service.


7. As a manufacturer and trader, we have a good quality and price control on our products.


8. Products are exported to more than 40 countries such as the United States, Canada, Mexico; Australia, New Zealand; Saudi Arabia, Italy, Spain; France, Poland, Israel, Russia, South Korea; Thailand, Indonesia, Malaysia, the Philippines, etc.


In the spirit of pursuing high-quality products and customer satisfaction, Shanghai Shigan Industrial Co,.Ltd solemnly promises you the principle of preferential price, thoughtful service and reliable product quality.


1.Product Quality Commitment:

(1). There are quality records and testing data for the manufacture and testing of products.

(2). For the inspection of product performance, we sincerely invite users to inspect the whole process and performance of the product in person. After the product is confirmed to be qualified, it will be packaged and shipped.


2. the product price commitment:

(1). Under the same competitive conditions, our company will sincerely provide you with a preferential price on the basis of not reducing the technical performance of the product or changing the product components.


3. Delivery time commitment:

(1). Product delivery time: as far as possible according to user requirements, if there are special requirements, it needs to be completed in advance, and strive to meet user needs.
